Product overview
The Canon imageFORCE C5140 – A3 Colour Laser Multifunction Printer brings printing, copying and scanning together for office document work. Its listed print performance is up to 40 ppm A4/A5*/A5R/A6R* · 21 ppm A3 · 24 ppm A4R (*1-sided only).
Specifications
| Brand | Canon |
|---|---|
| Model / series | imageFORCE C5140 |
| Product type | Printer |
| Control Panel | 10.1" TFT LCD WSVGA Colour Touch Panel |
| Standard Functions | Print, Copy, Scan, Send, Store, Optional Fax |
| Memory | Standard RAM: 6.0GB |
| Recommended Monthly Volume | 12,000 pages |
| Processor | 1.8GHz Dual Core Processor |
| Storage | Standard (SSD) 256GB · Optional (SSD) 1TB |
| Dimensions (W×D×H) | 620 × 722 × 937 mm |
| Weight | Approx. 105 kg |
| Print Speed | Up to 40 ppm A4/A5*/A5R/A6R* · 21 ppm A3 · 24 ppm A4R (*1-sided only) |
| Print Resolution | 4,800 × 2,400 dpi |
| Duplex Printing | Standard, automatic two-sided printing |
| First Copy Out | Approx. 4.1 / 6.1 seconds or less (BW/CL) |
| Scan Resolution | 600 × 600 dpi |
| Scan Speed | Up to 135 ipm (1-sided) · 270 ipm (2-sided) at 300 × 300 dpi (send); 80/160-90 ipm at 600 × 600 dpi (copy) (depends on document-feeder configuration) |
| Scanner Type | Single-pass Duplexing Automatic Document Feeder, up to 200 sheets [2-sided to 2-sided (Automatic)] |
| Scan Destinations | E-mail/Internet FAX (SMTP) · SMB3.0 · FTP · WebDAV · Mail Box (standard); Super G3 FAX, IP Fax (optional) |
| Scanned File Formats | TIFF (MMR) · JPEG · PDF (Compact, Searchable, Encrypted, PDF/A-1b, etc.) · XPS · Office Open XML (PowerPoint, Word) |
| Standard Paper Input | 1,200 sheets (100-sheet multi-purpose tray + 2× 550-sheet cassettes) |
| Max Paper Input (Optional) | 6,350 sheets (with High Capacity Cassette Feeding Unit-F1 + Paper Deck Unit-F2) |
| Custom Paper Size | 98.0 × 139.7 mm to 320.0 × 457.2 mm (multi-purpose tray) |
| Envelope Sizes | COM10 No.10 · Monarch · DL · ISO-C5 (custom 98.0 × 90.0 mm to 320.0 × 457.2 mm) |
| Media Types | Thin · Plain · Recycled · Eco · Colour · Heavy · Coated · Tracing · Bond · Transparency · Label · Pre-punched · Letterhead · Tab · Envelope |
| Media Weight | 52–300 gsm (multi-purpose tray) · 52–256 gsm (upper cassette) · 52–300 gsm (lower cassette) · 52–256 gsm (duplex) |
| Optional Accessories | Cassette Feeding Unit-AY1 · High Capacity Cassette Feeding Unit-F1 · Paper Deck Unit-F2 · Inner Finisher-N1 · Staple Finisher-AB3 · Paper Folding/Booklet Finisher-A2 |
| Toner Cartridges | C-EXV 1001 BK/C/M/Y · C-EXV 1001L C/M/Y |
| Connection Type | 1000Base-T/100Base-TX/10Base-T Ethernet · USB 2.0 (Host) x1 · USB 3.0 (Host) x1 · USB 2.0 (Device) x1 |
| Wireless Printing | Optional Wireless LAN (IEEE 802.11a/b/g/n/ac/ax) |
| Mobile Printing | AirPrint · Mopria · IPP Everywhere · Canon PRINT · uniFLOW Online · Universal Print by Microsoft · Cloud Connector |
| Fleet Management | uniFLOW Online · iW Enterprise Management Console · Remote Distribution & Management Service |
| Authentication | Picture Login · Card Login* · Username/Password · Department ID · Microsoft Entra ID · Two-Factor Authentication at LUI/RUI |
| Network Security | TLS 1.3 · IPSec · IEEE802.1X · SNMP V3.0 · Firewall (IP/MAC Filtering) · Dual Network Support · up to WPA3 |
| Device Security | SSD Data Encryption (FIPS140-3) · SSD Lock · Trusted Platform Module (TPM 2.0) · Automatic System Recovery · Trellix Embedded Control runtime intrusion detection |
| Colour | Colour |
Listed compatibility
SRA3 · A3 · A4 · A4R · A5 · A5R · A6R · B4 · B5 · B5R
Choosing this configuration
Compare the standard functions with the features you need. Optional feeders, finishers, fax kits, scanners, software and extra consumables are not included unless the chosen configuration expressly lists them. Print speeds depend on paper size, settings and job content; maximum resolutions and speeds may use different modes.
Product questions
Which accessories and consumables are supplied?
Use the selected configuration and the stated standard equipment as the reference. Confirm starter versus full-capacity consumables and any optional accessories before installation.
