Lenovo ThinkCentre M70t Gen 5 Desktop PC. This configuration includes Intel Core i7-14700, 20C (8P + 12E) / 28T, Max Turbo up to 5.4GHz, P-core 2.1 / 5.3GHz, E-core 1.5 / 4.2GHz, 33MB Intel Smart Cache, 1x 8GB UDIMM DDR5-5600, 512GB SSD M.2 2280 PCIe 4.0×4 NVMe Opal 2.0. Listed operating system: None.
Product specifications
| Part number | 12U60046GR |
|---|---|
| Processor | Intel Core i7-14700, 20C (8P + 12E) / 28T, Max Turbo up to 5.4GHz, P-core 2.1 / 5.3GHz, E-core 1.5 / 4.2GHz, 33MB Intel Smart Cache |
| Graphics | Integrated Intel UHD Graphics 770 |
| Chipset | Intel Q670 Chipset |
| Memory | 1x 8GB UDIMM DDR5-5600 |
| Memory Slots | Two DDR5 UDIMM slots, dual-channel capable |
| Max Memory | Up to 64GB DDR5 |
| Storage | 512GB SSD M.2 2280 PCIe 4.0×4 NVMe Opal 2.0 |
| Max Storage Support | Up to three drives, 1x 3.5" HDD + 1x 2.5" HDD + 1x M.2 SSD • 3.5" HDD up to 2TB • 2.5" HDD bay is only for customer self upgrade • M.2 SSD up to 2TB each |
| Card Reader | No Card Reader |
| Optical | None |
| Audio Chip | High Definition (HD) Audio, Realtek ALC623-CG codec |
| Speakers | 2Wx1 |
| Power Supply | 260W 90% |
| Keyboard | USB Traditional Keyboard, Black, Arabic |
| Mouse | USB Calliope Mouse, Black |
| Optional Bay | None |
| Expansion Slots | One PCIe 3.0 x16, full-height, length ≤ 222.7mm, height ≤ 111.2mm One PCIe 3.0 x1, full-height, (length ≤ 185mm, height ≤ 100mm) or (length ≤ 118mm, height ≤ 110mm) Two M.2 slots (one for WLAN, one for SSD) |
| Case Color | Black |
| Dust Filter | None |
| Pen | Pen Not Supported |
| Form Factor | Tower (13.6L) |
| Dimensions (WxDxH) | 145 x 296 x 346 mm (5.7 x 11.7 x 13.6 inches) |
| Weight | Around 5.9 kg (13.0 lbs) |
| WLAN + Bluetooth | Intel Wi-Fi 6E AX211, 802.11ax 2×2 + BT5.3, vPro |
| WWAN | WWAN Not Supported |
| Ethernet | Integrated 100/1000M |
| Front Ports | 1x USB-C (USB 5Gbps / USB 3.2 Gen 1), with 15W charging 4x USB-A (USB 5Gbps / USB 3.2 Gen 1) 1x headphone / microphone combo jack (3.5mm) 1x microphone (3.5mm) |
| Rear Ports | 4x USB-A (Hi-Speed USB / USB 2.0) 1x HDMI 2.1 TMDS 1x DisplayPort 1.4a (HBR2, DSC) 1x Ethernet (RJ-45) |
| Optional Rear Ports (configured) | None |
| Security Chip | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
| Fingerprint Reader | No fingerprint reader |
| Physical Locks | Smart Cable Clip Kensington Security Slot, 3 x 7 mm Padlock Loop |
| Smart Cable Clip | Smart Cable Clip |
| Chassis E-Lock | None |
| Chassis Intrusion Switch | None |
| System Management | Intel vPro Enterprise |
| Included Upgrade | None |
| Mil-Spec Test | MIL-STD-810H military test passed (Low Pressure [Altitude], High Temperature, Low Temperature, Temperature Shock, Humidity, Sand and Dust, Vibration, Shock, Solar Radiation, Contamination by Fluids, Salt Fog) |
| Operating System | None |
| Bundled Software | None |
| Bundled Accessories | None |
| Model | 12U60046GR |
| Machine Type | 12U6 |
| Region | MEA |
| Country/Region | UAE |
| TopSeller | Yes |
| EAN / UPC / JAN | 0198154946685 |
| Announce Date | 2024-08-06 |
| End of Support | 2030-11-15 |
