Product overview
Huawei S220-48P4X 48-Port PoE+ Gigabit Network Switch for connecting network devices.
Product details: weight with packaging: 4.29 kg (9.46 lb); weight without packaging: 3.24 kg (7.14 lb); typical power consumption: 49.44 W; maximum power consumption: Without PoE: 64.7 WFull PoE load: 462.8 W (PoE: 380 W).
Specifications
| Brand | Huawei |
|---|---|
| Product type | network switch |
| Weight with packaging | 4.29 kg (9.46 lb) |
| Weight without packaging | 3.24 kg (7.14 lb) |
| Typical power consumption | 49.44 W |
| Maximum power consumption | Without PoE: 64.7 WFull PoE load: 462.8 W (PoE: 380 W) |
| Static power consumption | 34.04 W |
| Number of fan modules | 2 |
| Types of fans | Built-in |
| Heat dissipation mode | Air cooling, intelligent fan speed adjustment |
| Airflow direction | Air intake from left, air exhaust from right |
| Long-term operating temperature | -5°C to +50°C (23°F to 122°F) at 0–1800 m altitude |
| Long-term operating relative humidity | 5% RH to 95% RH, non-condensing |
| Power supply mode | AC built-in |
| Power supply surge protection | Differential mode: ±6 kVCommon mode: ±6 kV |
| Switching capacity | 176 Gbit/s |
| Packet forwarding rate | 131 Mpps |
| Ge rj45 ports | 48 (PoE+) (1G/100M/10M) |
| Poe | Supported |
| Maximum poe power consumption | 380 W |
| Istack | Up to 4 switches in a stack |
| Chassis material | Metal |
| Dimensions without packaging (h × w × d) | Basic: 43.6 × 442 × 220 mm (1.72 × 17.4 × 8.66 in)Max depth: 43.6 × 442 × 227 mm (1.72 × 17.4 × 8.94 in) |
| Dimensions with packaging (h × w × d) | 90 × 550 × 360 mm (3.54 × 21.65 × 14.17 in) |
| Installation type | Rack mounting, Desk mounting, Wall mounting |
| Without poe | 64.7 WFull PoE load: 462.8 W (PoE: 380 W) |
| Differential mode | ±6 kVCommon mode: ±6 kV |
| Basic | 43.6 × 442 × 220 mm (1.72 × 17.4 × 8.66 in)Max depth: 43.6 × 442 × 227 mm (1.72 × 17.4 × 8.94 in) |
Choosing this product
Compare port speeds and uplink types. For PoE devices, check both the per-port limit and the total power budget against the connected equipment.
